HOME › PRODUCTS › Passenger Vehicle › 2024 Jaecoo J7 SHS / Tiggo 7 High Energy
2024 Jaecoo J7 SHS / Tiggo 7 High Energy
Passenger Vehicle
Plug-in Hybrid
Engine
SQRH4J15
Max Power
115kW
Max Torque
220N·m
Gearbox
DHT
Drive Type
Front-Wheel Drive
Top Speed
180km/h
Seats
5
EV Range
120km
Basic Information
| Manufacturer | Chery Automobile |
| Level | Passenger Vehicle |
| Energy Type | Plug-in Hybrid |
| Body Structure | 5-Seat · FWD · DHT |
| Length × Width × Height | 4501*1865*1670mm |
| NEDC Pure Electric Range | 120km |
| Rear Door Opening Method | Hinged door |
| Maximum Power | 115kW |
| Maximum Torque | 220N·m |
| Gearbox | DHT |
| Engine | SQRH4J15 |
| Top Speed | 180km/h |
| NEDC Combined Fuel Consumption | 1.27L/100km |
| Maximum Load Capacity | 2192kg |
| Curb Weight | 1775kg |
| Seats | 5 |
Level：Compact SUVRange：120kmSlow Charging Time：3hFast Charging Time：0.32hEnergy Type：Plug-in hybrid
Basic Information
| Manufacturers | Chery Automobile | Level | Compact SUV |
| Energy type | Plug-in hybrid | CLTC pure electric range | 120km |
| Gearbox | DHT | Body structure | 5-door, 5-seater SUV |
| Engine | 1.5T 156 hp L4 | Electric motor | 204Ps |
| Length * Width * Height | 4501*1865*1670mm | Top speed | 180km/h |
| WLTC combined fuel consumption | 1.27L/100km | Lowest state-of-charge fuel consumption (WLTC) | 4.9L/100km |
| Combined fuel consumption of oil and electricity | 1.72L/100km | Curb weight | 1775kg |
| Maximum load capacity | 2192kg |
Body
| Length | 4501mm | Width | 1865mm |
| Height | 1670mm | Wheelbase | 2672mm |
| Front wheel track | 1582mm | Rear wheel track | 1604mm |
| Approach angle | 20(°) | Departure angle | 23(°) |
| Body structure | SUV | Car door opening method | Hinged door |
| Number of car doors | 5 | Number of seats | 5 |
| Fuel tank capacity | 60L |
Engine
| Engine Model | SQRH4J15 | Displacement | 1.5L |
| Intake form | Turbocharging | Engine layout | Transverse |
| Cylinder arrangement | L | Number of cylinders | 4 |
| Maximum horsepower | 156 horsepower | Maximum power | 115kW |
| Maximum torque | 220N·m | Maximum net power | 105kW |
| Energy type | Plug-in hybrid | Fuel supply method | Direct Injection |
Electric motor
| Front Motor Model | KPTZ220YMDA0 | Motor Type | Permanent magnet/synchronous |
| Total power of electric motor | 150kW | Total horsepower of electric motor | 204Ps |
| Total torque of electric motor | 310N·m | Maximum power of front motor | 150kW |
| Maximum torque of front motor | 310N·m | Number of drive motors | Single motor |
| Motor layout | Front |
Battery/Charging
| Battery Type | Lithium iron phosphate batteries | Battery cell brands | Freddie/CALB |
| Battery cooling method | Liquid Cooling | CLTC pure electric range | 120km |
| Electricity consumption per 100 kilometers | 15.2kWh/100km | Fast charging power | 45kW |
Gearbox
| Number of gears | Continuously Variable Transmission (CVT) | Transmission type | Dedicated Hybrid Transmission (DHT) |
Chassis Steering
| Drive type | Front-engine, front-wheel drive | Front suspension type | MacPherson independent suspension |
| Rear suspension type | Multi-link independent suspension | Assistance type | Electric assist |
Wheel Braking
| Front brake type | Ventilation disc | Rear brake type | Disc |
| Parking brake type | Electronic parking brake | Front tire specifications | 235/50 R19 |
| Rear tire specifications | 235/50 R19 |
| Length | 4501mm |
| Width | 1865mm |
| Height | 1670mm |
| Wheelbase | 2672mm |
| Curb Weight | 1775kg |
